Fully automatic hammer mill sea salt grinder crushing pulverizer
- Wonsen
- China
- 90 days
- 50/Month
The head is easy to disassemble.
Crushing particle size 60-400 mesh.
The opening rate of the screen is up to 40%.
Fully automatic hammer mill sea salt grinder crushing pulverizer
Application
The modular, compact and user friendly concept of the Hammer Mill with both knife and hammer side to deal with both crystal and flexible products for the pharmaceutical, chemical and foodstuffs industries.
The Hammer mill is distinguished by its compact design, user-friendliness and easy-clean features. The large active screening surface and the high peripheral velocity – indispensable for regular product distribution on the sieve surface - play an important role in achieving high throughput. The product is impacted by the rotor and then sieved by the scree below the rotor.
Technical Parameter
No. | Name | Description | Remarks |
01 | Power supply | AC 3x380V, 50Hz, 3L+PE+N | |
02 | Control voltage | DC 24V | |
03 | Compressed air | >3 Bar, Consumption > 400NL/min, 2xφ8mm | |
04 | Rotor | 1 x 8 knives with thickness of 6mm, SS 316 | |
05 | Sieve | 1 x Sieve, from 0.2mm to 10mm | 0.15 or 0.2mm |
06 | Rotor Speed | 2000 rpm – 12000 rpm | |
07 | Motor | 2.2kW, 2P, 3000rpm @ 50Hz can be used under 5~100 Hz | China (can optional with explosion proof) |
08 | Frequency Convertor | China | |
09 | Bearing | NSK | |
10 | Lip Seal | PS lip, 22x38x0.8 | Garlock |
11 | HMI | Smart 700 | Siemens |
12 | PLC | S7-200 | Siemens |
13 | Coupling | Customized type, EZ2 series | R+W |
14 | Pressure Regulator | GFR300-10-F1 | AirTAC |
Part of Production & Inspection Equipment
1.Your enquiry or questions will reponse once we receive it!
2.Providing technical data,high-definition pictures,flow chart that all you need
3.Supply the validation documents and certificates.
4.OEM/ODM is available.
5.Providing long-term after-sale service,door-to-door service and corporate training
Low cost high quality pharmaceutical multi mill or pharmaceutical cone mill
Why choose us
1.Specialized in designing, developing and manufacturing.
2.Above 130 National patents,national and provincial technology innovation awards
3.Provincial Pharma Equipment Engineering Technology Research Center
4.National High-Tech,National Pharma Equipment Industry Association,Provincial new special expertise Enterprises
5.Manufacture the solid preparation production line equipment for above 500 domestic and oversea enterprises
6.Modern production workshop and production line of high-end manufacturing equipment
7.Professional and efficient after-sales service management
8.Competitive price and prompt delivery
9.Meet ISO9001 and CE
10.OEM/ODM available
Low cost high quality pharmaceutical multi mill or pharmaceutical cone mill
Our Company View
Company information
Yichun Wanshen Pharmaceutical Machinery Co., Ltd. is a research, development, production and sales of pharmaceutical equipment, Well-known manufacturer that providing domestic and overseas users with first-class equipment that conforms to GMP, CGMP and whole-set solutions. The main products include dispensing, granulating, drying, mixing, transferring (lifting) and coating series. They passed CE, ISO9001:2008 certificate. In addition, we also provide a chain of services including whole-set equipment design, production, installation, commissioning and project management for such industries as health products, food, new energy and chemical industry.
We are located in a national-level economic development zone in Yichun City of Jiangxi Province .With a land area of 40,000m2, a construction area of 38,000m2 and fixed assets of RMB 80 million Yuan.The products have been awarded more than 130 national patents, Such as Utility Patent, Invention Patent, Design Patent certificates etc. And the closed granulating, drying and granule sizing equipment has been awarded Technical Innovation Project of middle and small-sized Enterprises of National Science &Tech, Key Innovation Fund Project in Jiangxi Province and Key New Product in Jiangxi Province.
We offer high quality, the most competitive price and prompt delivery. Our experienced staff members are always available to discuss your requirements and ensure full customer satisfaction. Selling well in all cities and provinces around China, our products are also exported to clients in such countries and regions as Eastern Asia, Mid East, Africa, Southeast Asia, Oceania, South America, North America, Europe. We also welcome OEM and ODM orders. Whether selecting a current product from our catalog or seeking engineering assistance for your application, You are welcome to talk to our customer service center.
Exhibitions and Customers
FAQ
1.How long for the delivery?
Within 45 days after receiving the deposit.
2.What's the payment terms?
T/T, L/C,Cash,West union etc.
3.OEM and ODM?
Yes
4.How long is the warranty period?
One year after shipment
Welcome to contact us
