Cream Vacuum Homogenizing Emulsifier
- Wonsen
- China
- 60
- Always Available
The cream vacuum homogenizing emulsifier integrates mixing, dispersing, homogenizing, emulsifying, and vacuum degassing functions. It performs high-shear emulsification on high-viscosity materials under a vacuum environment, making it ideal for the large-scale production of cosmetic creams and lotions, topical pharmaceutical ointments, daily chemical pastes, and various creamy emulsified foods.
Application
The cream vacuum homogenizing emulsifier integrates mixing, dispersing, homogenizing, emulsifying, and vacuum degassing functions. It performs high-shear emulsification on high-viscosity materials under a vacuum environment, and is widely applicable to the large-scale production of cosmetic creams and lotions, topical pharmaceutical ointments, daily chemical pastes, and various creamy emulsified foods.
Features
1. Highly Efficient Homogenizing & Emulsifying: Integrates multiple functions including mixing, dispersing, homogenizing, and emulsifying into one unit, enabling streamlined production processes.
2. Vacuum Degassing & Defoaming: Effectively eliminates air bubbles within the materials, significantly enhancing product stability and overall quality.
3. High-Viscosity Adaptability: Capable of handling materials with a viscosity of up to 100 Pa·s, easily accommodating diverse formulations and process requirements.
4. Stable & Efficient Production: Features a high level of intelligent automation, ensuring smooth and highly reliable performance.
Technical parameter
| Model | WSZRG-350 | WSZRG-500 | WSZRG-750 | WSZRG-1000 | WSZRG-1500 | WSZRG-2000 | |
|---|---|---|---|---|---|---|---|
| Effective Volume (L) | 350 | 500 | 750 | 1000 | 1500 | 2000 | |
| Working Pressure (bar) | -1~2.5 | ||||||
| Operating Temperature (℃) | -10~150 | ||||||
| Speed of Agitator (rpm) | ≤40 | ||||||
| Material Viscosity (mPas) | ≤100000 | ||||||
| Homogenizer Speed (rpm) | ≤3500 | ||||||
| Overall dimensions (mm) | 3700*2600*2500 (3600) | 4000*2900*2950 (4000) | 3780*3200*3050 (4380) | 3900*3400*3150 (4550) | 4000*4100*3750 (5650) | 4850*4300*3600 | |
| Total Power (kW) | 17 | 19 | 24 | 29 | 42 | 46 | |
